Chapter 2 Cutting
51
5
Set the clamps at both edges to High mode.
• "Setting the Clamp High/Low Mode"(P. 57)
6
If using three pinch rollers, select High mode or Low mode for the center clamp as appropriate
to suit the sheet being used.
• "Setting the Clamp High/Low Mode"(P. 57)
7
The center clamps can be enabled or disabled when using three pinch rollers.
• "Enabling and Disabling the center clamp"(P. 57)
• The center clamp should be enabled (center clamp up) if you do not wish leave pinch roller marks
on the sheet.
8
Pull out the sheet tight to eliminate any sagging.
9
Check to confirm that the sheet has been loaded without any sagging, then pull the clamp
lever toward you.
10
Check to confirm that the pinch rollers are evenly spaced.
• Hold the sheet between the pinch rollers and grit rollers.
• If the spacing is not uniform, repeat all steps from the start.
11
Press or to select [ROLL].
• "Note about sheet detection"(P. 45)
• : If the roll sheet was loaded from the rear of the machine
• : If the roll sheet was loaded from the front of the machine
• Pressing the [FEED] key displays a screen for selecting the number of pinch rollers before
sheet detection. Select the number of pinch rollers before performing sheet detection.
The number of pinch rollers set here takes precedence over the number of pinch rollers
using the [SET UP] - [PINCH ROLL.] menu.
2
To Next Page
