MIMAKI JV4-180 User Manual

– 2.6 –
Main PCB connector signals
Connector Pin No. Signal Name Remarks
1 +5V
2 GND
3 LCD-E
4 RS1
5 LCD-RW
6 LCD-D0
7 LCD-D1
8 LCD-D2
9 LCD-D3
10 /KEY-E
11 RS2
12 K-LED Not used
1 +5V
2 X-ENCA
3 X-ENCB
4 N.C
5 GND
6 GND
1 +X-MV
2 N.C
3 -X-MV
1 +5V
2Y-ENCA
3Y-ENCB
4 GND
5 GND
1+Y-MV
2-Y-MV
1 +COVER
2 N.C
3 -COVER
1 +35V
2 +35V
3 GND
4 GND
5 +5V
6 GND
7 N.C
8 X-SEN Not used
9 SPCK-I1
10 SPLD-I1
11 SPDA-I1
12 SPCK-O1
13 SPLD-O1
14 SPDA-O1
15 SPCK-O2
16 SPLD-O2
17 SPDA-O2
18 P-CK1
19 P-CK2
20 P-CK3
21 P-CK4
22 P-CK5
23 P-CK6
24 P-CK7 Not used
25 N.C
26 PWM1
27 GATE
28 RESET
29 H-ST Not used
30 H-ON Not used
31 H-PR Not used
32 W-ENC Not used
33 IO-V0
34 IO-V1
CN5
CN6
CN7
CN8
CN9
CN10
CN13
Connector Pin No. Signal Name Remarks
1 +5V
2 GND
3 SPCK-I2(3)
4 SPLD-I2(3)
5 SPDA-I2(3)
6 SPCK-O3(4)
7 SPLD-O3(4)
8 SPDA-O3(4)
9 ID-IN Not used
10 ID-OUT Not used
11 GATE
12 N.C
A1 +35V
A2 +35V
A3 +35V
A4 N.C
A5 N.C
A6 IFRESET
A7 IF-RDnWR
A8 PWDWN Not used
A9 WUPRQ Not used
A10 IF-nPREQ
A11 IF-DRQ0
A12 IF-DRQ1
A13 INNDREQ3 Not used
A14 INNDREQ4 Not used
A15 IFA0
A16 IFA1
A17 IF-RWCLK
A18 IF-CKIO
A19 IF-IDOUT
A20 IFD0
A21 IFD2
A22 IFD3
A23 IFD5
A24 IFD6
A25 IFD8
A26 IFD9
A27 IFD11
A28 IFD12
A29 IFD14
A30 IFD15
A31 IFD17
A32 IFD18
A33 IFD20
A34 IFD21
A35 IFD23
A36 IFD24
A37 IFD26
A38 IFD27
A39 IFD29
A40 IFD30
B1 +5V
B2 +5V
B3 +5V
B4 +3.3V
B5 +3.3V
B6 +3.3V
B7 SEQREQ Not used
B8 PWACK Not used
B9 GND
B10 GND
B11 IF-DRQ2
B12 GND
B13 INNDREQ5 Not used
B14 GND
B15 IF-CS
CN14 /
(CN15)
CN17
