MIMAKI JV4-180 User Manual

– 2.7 –
Connector Pin No. Signal Name Remarks
B16 GND
B17 GND
B18 GND
B19 IFD1
B20 GND
B21 IFD4
B22 GND
B23 IFD7
B24 GND
B25 IFD10
B26 GND
B27 IFD13
B28 GND
B29 IFD16
B30 GND
B31 IFD19
B32 GND
B33 IFD22
B34 GND
B35 IFD25
B36 GND
B37 IFD28
B38 GND
B39 IFD31
B40 GND
1 GND
2 SCK
3 GND
4 SNLD1(2)
5D0
6D1
7D2
8D3
9D4
10 D5
11 D6
12 D7
13 GND
14 SDI1(2)
15 SDRQ1(2)
16 HNINTR1(2)
17 REJ1(3)
18 REJ2(4)
19 SUB1(3)
20 SUB2(4)
21 LE1(2)A
22 LE1(2)B
23 LE1(2)A-R
24 LE1(2)B-R
25 GND
26 40MSCK+
27 40MSCK-
28 GND
29 +3.3V
30 +3.3V
31 GND
32 GND
33 +5V
34 +5V
35 GND
36 +35V
37 +35V
38 +35V
39 +35V
40 +35V
CN18 /
(CN19)
CN17
Connector Pin No. Signal Name Remarks
1 +5V
2UDINO
3 UDINI Not used
4 GND
1 +COVER
2 N.C
3 -COVER
CN21
CN21
