– 4.31 –
a. Plotting a density pattern
1) Select the density pattern using the or
key and press the
ENTER
key.
Pattern : 100%, 50%, 25%, 6.25%
2) Select the resolution using the
or key
and press the
ENTER
key.
Resolution : 360 x 360- N1, 360 x 360- V1
360 x 540- N1, 360 x 540- V1
720 x 720- N2, 720 x 720- V2
1440 x 1440 -V2, 180 x 180- N1
3) Select the drawing way using the
or
key and press the
ENTER
key.
Drawing way : BI-D 1,2,3,4,6,8,12,16,32 pass
UNI-D 1,2,3,4,6,8,12,16,32 pass
• Some items cannot be selected
depending on the resolution.
4) Select the plotting length in the XandY-
direction using the
or key and press
the
ENTER
key.
Length setting: 10 mm to the sheet length (in
increments of 10 mm)
5) Select the ink type used for plotting using the
or key and press the
ENTER
key.
# CHK PATTERN
PATTERN : 100%
# CHK PATTERN
DPI : 360X360-N1
# CHK PATTERN
PLOT : UNI–D 2 pass
# CHK PATTERN
X = 10 Y = ∗ ∗ ∗ ∗ ∗
# CHK PATTERN
INK TYPE : Pigcm
( Select several)
