– 4.32 –

6) Select the color used for plotting.

Shift the cursor using the

or key to select

the color to be used.

Press the

or key to select wheter the

color is drawned or not.

Press the

ENTER

key to finalize the

number.

7) At this time it is now ready for the drawing.

Press the

ENTER

key to start drawing.

When the device is ready for plotting, the

followings can be setted.

: shift the origin.

REMOTE/LOCAL

: select the head used and the

high-speed scan.

Plotting can be aborted by pressing the

key.

8) After the completion of the plotting, press the

key in repetition to return the

layers of screens one by one to permit the

conditions to be changed.

# CHK PATTERN

COLOR : KCMY––

# CHK PATTERN

PATTERN : PLOT

b. Plotting a nozzle checking pattern

1) Select “NOZZLE” using the or key

and press the

ENTER

key.

2) Select the resolution using the

or key

and press the

ENTER

key.

Resolution : 360 x 360- N1, 360 x 360- V1

360 x 520- N1, 360 x 520- V1

720 x 720- N2, 720 x 720- V2

1440 x 1440 -V2, 180 x 180- N1

# CHK PATTERN

DPI : 360X360-N1

# CHK PATTERN

PATTERN : NOZZLE
