Special Imaging Modes
11-16
If the Eraser mode is selected, with the eraser moving the region that will be cut is defined
in real time.
Click [Undo] in the soft menu to undo the last cutting; click [Restore] to restore the cut
region; or click [Undo All] to undo all cuttings.
5. Click [Exit] to exit the cutting status.
Parameters are described as follows:
Type Parameter Description
Edit Type
C. inside
Allows you to trace the portion of the image you want to cut.
Inside Contour removes all portions of the image that fall
inside your traced region.
C. outside
Allows you to trace the portion of the image you want to cut.
Inside Contour removes all portions of the image that fall
outside your traced region.
R. inside
Displays a box you can use to define the portion of the image
you want to cut. Inside Rect removes all portions of the
image that fall inside the box.
R. outside
Displays a box you can use to define the portion of the image
you want to cut. Outside Rect removes all portions of the
image that fall outside the box.
Eraser. B
Provides a big eraser tool you can use to define the portion
of the image to cut by hand.
Eraser. S
Provides a small eraser tool you can use to define the
portion of the image to cut by hand.
P. outside
Allows you to trace a polygon on the image you want to cut.
Outside Polygon removes all portions of the image that fall
outside your traced region.
P. inside
Allows you to trace a polygon on the image you want to cut.
Inside Polygon removes all portions of the image that fall
inside your traced region.
Edit Depth Depth
Function: allows you to define the image depth to be cut.
3D image changes in real time along with the depth.
Full: the full depth of the selected region will be cut.
Define: allow you to define the depth to be cut. When [Full
Depth] is “Off”, you can define the depth by clicking [Edit
Depth]. The range is 0%-100%, in increments of 5%.
Other
Operations
Undo To undo the last cut only.
Redo To restore the cut region.
Undo All To undo all cuts since you entered image edit mode.
Done Click to confirm the edit.
Tips: if you click [Reset ROI] item, all operations for image editing will be cleared.
11.1.6.8 Comment and Body Mark
 Function:
Add comment and body mark to the sectional planes and 3D image.
