Wireless LAN
A-3
3. Click the wireless LAN manager icon
in the lower right corner of the toolbar
region, and the manager dialogue box pops up:
z [Connect]: select the target network and click to connect, and the manager icon
turns
after connected.
z [Disconnect]: select the target network and click to disconnect.
z [Refresh]: click to update the wireless network list.
z [Configure]: click to enter the “Local TCP/IP” setting screen.
z [Show Detail]: click to view the connection information of the wireless network, and
select [Export] in the prompted dialogue box to save the information.
z [Set Preferred Network]: click to set the selected network to be a default
connecting network, and the system will automatically connect to this network
after detecting it.
z [Delete Profile]: click to delete the preferred network setting and password that
has been entered.
NOTE: 1. When connecting an encrypted network, entered password will be
remembered by the system.
2. When there is more than one wireless router in the LAN, DO NOT disable the
DHCP function of the current router.
3. If error password has been entered when connecting an encrypted network,
click [Delete Profile] and reconnect the network.
Tips: if abnormal network performance is detected, e.g. wireless network list is not
updated in time; you may take the following measures:
1. Connect/disconnect the network adapter again.
2. Restart the router and ultrasound system if the problem is not fixed.
Restart the router again and wait for 5-10 min and reconnect the network again if the
problem is not fixed.
A.2 To Install Drive for Wireless Adapter
You can install drive for wireless adapters through the following path (take DWA-125
D-LINK as an example):
a) Acquire the License file from the service engineer.
b) Press <Setup> to enter the Setup menu.
c) Move the cursor onto [Network Preset], select [Setup Wireless Driver] to
open the screen, as shown in the figure below:
To Next Page
