Ultrasound System Comprehensive PM Form
INFORMATION
Account Name
Model Name
Model Serial Number
Software Version
Work Order Number
TEST EQUIPMENT
Leakage Tester Make
Simulator Make
Leakage Tester Model
Simulator Model
Leakage Tester SN
Simulator SN
Leakage Tester Cal. Date
Simulator Cal. Date
Phantom Make
Phantom Model
Phantom SN
ELECTRICAL SAFETY
Ground resistance(ohms)
Leakage/Patient
(Probe/ECG Wire) (uA)
Leakage/Chas. (uA)
FUNCTIONAL / PHYSICAL / MECHANICAL CHECK
Self diagnosis
Pass Fail N/A
Power cord, adapter/breaker
Pass Fail N/A
Casters, brakes
Pass Fail N/A
Air filter
Pass Fail N/A
Control panel
Pass Fail N/A
Battery
Pass Fail N/A
Trackball
Pass Fail N/A
CD/DVD drive
Pass Fail N/A
Handle, latch, door, etc.
Pass Fail N/A
ECG
Pass Fail N/A
Monitor, touch screen
Pass Fail N/A
Network, USB ports
Pass Fail N/A
Monitor arm
Pass Fail N/A
Peripheral devices
Pass Fail N/A
Display performance
Pass Fail N/A
TRANSDUCER #1
Probe Model
Probe SN
Physical / Mechanical Check
Pass Fail
Depth of Penetration(cm)
Uniformity(brightness)
Pass Fail
Uniformity(element dropout)
Pass Fail
Geometric Accuracy(axial)
Pass Fail
Geometric Accuracy(lateral)
Pass Fail
TRANSDUCER #2
Probe Model
Probe SN
Physical / Mechanical Check
Pass Fail
Depth of Penetration(cm)
Uniformity(brightness)
Pass Fail
Uniformity(element dropout)
Pass Fail
Geometric Accuracy(axial)
Pass Fail
Geometric Accuracy(lateral)
Pass Fail
TRANSDUCER #3
