DICOM
Page
Description of Control
Storage
Configure a DICOM destination including AE Title, port, transfer
specifics and options, and image/clip specifics and options.
Print
Configure a DICOM printer destination including AE Title, port, transfer
specifics and options, image/clip specifics and options, and print
specifics and options.
Worklist
Configure a MWL source including AE Title, port, and data transfer
specifics.
MPPS
Configure Modality Performed Procedure Step which is used to send
exam state information to the configured server. This facilitates the other
systems in obtaining the exam progress in time.
Storage
Commitment
Configure storage commitment parameters including AE Title, port,
transfer specifics and options.
Query / Retrieve
Configure parameters of querying and retrieving patient exam records in
a designated server, including AE Title, port, transfer specifics and
options.
HL7 Query
Configure network specifics relating to HL7
HL7 refers to the medical information exchange protocol on the seventh
layer (application layer) of the Model of the Open System
Interconnection published by ISO. It is established by Health Level
Seven International in 1987.
HL7 is mainly used for standardizing the communication between
HIS/RIS system and the other devices, reducing the information
interconnection costs among hospitals, and improving the data usability
for hospital information system.
Network
Network
Description of Control
Network
Configure network specifics including IP address, Gateway, Subnet Mask,
MAC address
Configure a wireless bridge.
FTP
Configure an FTP destination including IP Address, password, port, and
data transfer mode.
QPath/
Q-View
Configure (import, backup, restore, and delete) QPath worksheet linkages
and passwords
Configure Q-View, which is a client viewing tool for the server.
The primary purpose of Q-View is to provide remote access to Q-Path from
the ultrasound system, thereby, allowing the users to complete the exam
report on the ultrasound system and submit.
VPN
Configure a Virtual Private Network (VPN) connection including Server IP,
Group, User Name and Password to allow for encrypted transfer.
