cine-loop images and navigating
form/tables/worksheets/reports.
Press to cycle through different
menus the Priority key while
multiple imaging mode menus
are available, for example M, B
and Cine modes.
DGC Slide pots Changes gain
of image at discrete depths (8
Sliders).
Prints an image to a printer or
stores an image or clip to
media, depending on
configuration.
Activates/deactivates DUAL
imaging mode.
Press to display the Annotation
softkeys for the selected
exam/preset and transducer.
Used to enable controls for
Stress Echo or Automatically
Tutorial Workflow protocols.
Keyboard Functions
Figure 4.4-ZS3 keyboard keys and function
