Mindray Zonare ZS3 Service Manual

ZS3 Service Manual
Page 39 of 295
Key
System Control
Description
1
NEW PATIENT
This is a toggle key. The first press will display the Patient
Information page. The second press will return to the imaging
display.
2
CURRENT EXAM
If there is an exam in progress, pressing this key will display the
in-progress exam's images, most recently stored image displayed
first. If there is no exam in progress, pressing this key will have no
effect.
3
PG BACK
This key only works when in in-progress exam review or archived
exam review. Pressing this key will display the previous image, or
page of images if in a multi-image display format. Once the first
page is reached, the key press will have no effect.
4
PG FWD
This key only works when in in-progress exam review or archived
exam review. Pressing this key will display the next image, or
page of images if in a multi-image display format. Once the last
page is reached, the key press will have no effect.
5
FIRST LAST
This key only works when in in-progress exam review or archived
exam review. Pressing this key will toggle between the first stored
image (or first page of images in a multi-image display format)
and the last stored image (or last page of images in a multi-image
display format).
6
DELETE
This key only works when in in-progress exam review or archived
exam review. When an image has been selected, pressing the
Delete key will tag the image for deletion by drawing a red X
through it. If the selected image already has been tagged for
deletion (red X) pressing the Delete key will remove the red X,
untagging the image.
7
FORMAT
This key only works when in in-progress exam review or archived
exam review. Pressing this key will toggle between the following
image formats: 2 x 2, displaying 2 rows of 2 images (4 images); 3
x 2, displaying 2 rows of 3 images (6 images); and a full-size
image.
8
ARCHIVE
This is a toggle key. The first press will display the Patient
Selection Table. The second press will return to imaging.
9
END EXAM
When an exam is in progress, pressing the End Exam key will
close the exam. If no exam is in progress, pressing this key will
have no effect.
10
DICOM QUEUE
This is a toggle key. The first press will display the DICOM Task
Management page. The second press will return to imaging.
11
ECG
CARDIAC Option Systems ONLY: This is a toggle key. The
pressing of this key will activate ECG operation and display the
ECG trace on the monitor. A repeat press will turn off this
function.
12
SERVICE
This is a dual-function key. A “quick” momentary press is a
shortcut to bring up the USER DIAGNOSTIC PANEL screen. An
