Mindray Zonare ZS3 Service Manual

ZS3 Service Manual Page 218 of 295
19 Replacement Procedures
The procedures described in this section of the Service Manual should be performed
ONLY by a Mindray/Zonare trained service personnel (Service Engineer, Biomed,
etc.).
Recommended Tools
Tool Description
Size
Qty
Where used
Screwdriver, flat blade, medium tip, std.
length
3mm blade,
6” shaft, std.
thick
1
General use
Screwdriver, Phillips, large tip, std
length
#3, 6” shaft
1
Power supply module
Screwdriver, Phillips, med. tip std
length
#2, 6” shaft
1
General Assembly
Screwdriver or Allen Wrench
4mm, 6” shaft
1
Power supply module, Dock,
ZPAK
Pliers, Diagonal Cutters, small
Small jaws
1
General cutting of tie wraps, etc.
Nut-Driver Set (U.S.)
Multi-sizes
1 set
Display
Socket Wrench Set, (10mm, 13mm)
Multi-sizes
1 set
Gas spring (13mm)
Allen Wrench Set (Metric)
2.5mm, 5mm
4mm
1
Gas spring
Dock, ZPAK and Power Module
Flashlight, Mini-Mag
6” size
1
Illuminating tight access areas
Magnetic pick-up tool
Telescoping
1
Retrieval of hardware
Wrench (042-007605-00)
22mm&
36mm
1
Assembling and disassembling
the caster
