ZS3 Service Manual Page 170 of 295
16 Care and Maintenance
Overview
This section describes the maintenance, care and service recommended to maintain
the ZS3 system in proper operation.
Mindray ultrasound systems are designed to be maintenance free. Our ultrasound
systems do not require regular preventative maintenance such as calibration or
adjustments to the hardware and transducers. Mindray has developed procedures to
allow you to perform annual quality checks designed to support your facilities Quality
Control requirements. For customers without the necessary equipment or resources to
perform these checks, Mindray can provide this service for a fee.
WARNING: Shock hazards exist if the AC power connection for the ZS3 system or
AC adapter are not properly grounded. Equipment must be connected to a hospital
grade receptacle. Do not remove the grounding wire.
The enclosures contain no operator-serviceable components other than the
scanner module.
To avoid electrical shock, do not remove covers other than the scanner module
cover.
For servicing, contact Mindray/Zonare Technical Support only. Failure to do so
may void your warranty or service contract coverage.
To safely use and maintain the system:
To avoid electrical shock, always disconnect the AC power before cleaning
any part of the ZS3 system.
Do not immerse the transducer past the cleaning/disinfection level depth
specified in “Cleaning and Disinfecting Transducers.” Do not immerse the
transducer for longer than specified cleaning/disinfecting time. Do not use
any transducer that has been immersed beyond the Improper cleaning or
disinfection of any part of the ZS3 system can cause permanent damage.
Follow the cleaning and disinfection instructions.
CAUTION: Do not excessively twist or bend the cables; this can cause failure
Improper cleaning or disinfection of any part of the ZS3 system can cause
permanent damage. Follow the cleaning and disinfection instructions
