ZS3 Service Manual

Page 27 of 295

Battery Pack Specifications

Type

Parameter

Value

Electrical

Power rating

15.6V, 15Ah = 234 Wh

Chemistry

NiMh

Physical

(weight)

4kg (10 lb.)

Operational

Operating time duration

(fully charged)

Up to 1.5 hours

Physical

(dimensions)

Height

75 mm (3 in.)

Width

260 mm (10 in.)

Depth

355 mm (14 in.)
