ZS3 Service Manual Page 259 of 295
Gas Spring – Removal/Replacement
Required Parts
P/N: 33073-00 Assy, Gas Spring, Gen II Cart
Required Tools/Equipment
#2 Phillips Screwdriver
5mm Allen Hex wrench
13mm socket, used on a ratcheting wrench
9/32” Nut Driver or wrench
Prerequisite Procedures to Be Performed:
18. Main Power Supply Module - Removal
Overview of Procedure
19. Removal of gas spring
20. Re-installation of above items
21. Verification of system operation
Main Power Supply Removal:
22. Perform Main Power Supply Module Removal
(NOTE: Refer to Main Power Supply Replacement Procedure in this manual)
Gas Spring Removal:
1. Using the side of the hand – firmly knock the side of the plastic cosmetic sleeve
loose. There are 3 spring clips that retain it at the top. If it does not come free –
gently use the flat blade screwdriver to pry the cosmetics loose (use tape on
the blade to avoid marring the chassis surface).
