If either component fails to start up after these steps, contact Mindray/Zonare Tech
Support.
PERIPHERAL PROBLEMS
 19” Display monitor, no video
 Power down the system, then switch off circuit breaker (at rear of system) to
remove power to system electronics.
 Remove cover on back of monitor, and inspect/verify the cable connection.
 Sony B/W printer fails to power on
 Check the power cord connections.
 Temporarily connect the power cord of the peripheral to a local receptacle, and
test for operation of the peripheral.
 If the peripheral fails to power on after these steps, contact Mindray/Zonare Tech
Support.
 Sony B/W printer fails to print
 Check that the printer has paper available.
 Verify power button on the printer is on.
 Ensure that the USB cable is properly connected on the peripheral device, and
connected internally to the USB Hub under the user interface and consult
following table.
Lamp
Status
Cause/remedies
(green)
On
Printer powered on
PRINT (green)
On
Printing
Blinks
Receiving image data
Blinking slowly
Standing by until the thermal head is
ready for printing. Wait until the PRINT
lamp lights. Printing resumes
automatically.
PAPER (orange)
On
Add or reseat paper roll
ALARM (orange)
On
Door open > close door until it latches.
Printer malfunction > Turn the printer off
and back on. If error persists, contact
