Mindray Zonare ZS3 Service Manual

ZS3 Service Manual
Page 25 of 295
Width
51.5 cm (20.2 in)
Depth
72 cm (28.3 in.)
Type
Parameter
Value
IO
connectors
Ethernet (1 port)
RJ-45 – 10/100BaseT
USB 2.0 (3 ports)
USB-Type A (Vbus 5.0V, 0.5A
max)
Serial Port (1 port)
eSATAp
External Video (1 port)
HDMI 1280X1024
+Wireless
Option
Manufacturer
B&B Electronics / Quatech
Manufacturer type:
ABDN-ER-DP551U
Wireless Technology
IEEE 802.11b/g, WiFi compliant
Wired Interface
10/100 Ethernet (auto sense),
RJ-45 Plug
Frequency
DSSS, CCK, OFDM
Modulation Technology
DSSS, CCK, OFDM
Modulation Type
DBPSK, DQPSK, CCK, BPSK,
QPSK, 16QAM, 64QAM
Network Access Modes
Infrastructure, Ad Hoc
Channels
USA/Canada: 11 channels
Europe: 13 channels
France: 4 channels
Japan: 14 channels (13
channels for 802.11g)
Wireless Data Rate
802.11b = 11, 5.5, 2, 1 Mbps
802.11g = 54, 48, 36, 24, 18,
12, 9, 6 Mbps
MAC
CSMA/CA with ACK, RTS, CTS
Network Protocols
TCP/IP, ARP, ICMP, DHCP,
DHS, HTTP, UDAP Discovery,
TFTP, UDP, PING
Receive Sensitivity
54Mb/s = -69dBm
6 Mb/s = -86dBm
1Mb/s = -86dBm
Wireless Security
Disabled, WEP 64 & 128bit,
WPA (TKIP), WPA (AES),
WPA2 (AES),
802.1x (EAP),
Supports WPA & WPA2
Enterprise, EAP-
TLS/MSCHAPV2,
EAP-TTLS/MSCHAPv2,
EAP-TTLS(MD5),
EAP-PEAPv0/MSCHAPv2,
LEAP
