144
C
ABLING INTERFACES
CHAPTER 4 INSTALLATION
Subnets
You can assign up to 10 subnets that can be assigned to any network interface. Make sure that the IP
address ranges of the different subnets are not overlapping.
Static routes for eth0
You can program Static IP routes, which belong to the network interface (eth0) interface.
Status Connection status (Up or Down) of the Ethernet port
Carries Physical connection status of a network cable (Plugged
or Unplugged)
DHCP
Click DHCP to address the SMB Controller through
DHCP. If DHCP is disabled, the network parameters
must be entered manually. For static addressing of the
SMB Controller (recommended), enter a fixed IP
address, subnet mask, and the IP address of the
default gateway in the respective fields.
IP address IP address of the SMB Controller. For example:
192.168.104.13
Subnet mask Range of the subnet. For example: 255.255.255.0
Gateway IP address of the default gateway. For example:
192.168.104.1
MTU MTU stands for Maximum Transaction Unit. It is
defined as the maximum size of each packet
transmitted in a single network transaction.
MAC address MAC address of the Ethernet NIC card. There are four
Ethernet ports (eth0 ... eth3), each having a unique
MAC address. lt;Model name>-lt;MAC-Address>
Table 4.36:Subnets
Parameter Parameter value
Interface A physical network interface from eth0-eth3.
Description Free text that is used for subnet configuration.
IP address IP address of the subnet.
Subnet mask Defines the range of an IP address, which are available
for this network.
Gateway IP address of the gateway.
Table 4.35:Default values, IP address (Continued) (Sheet 2 of 2)
