Mitsubishi F700 Series User Manual

58
Parameter list
Automatic
restart functions
57
Restart coasting time
0, 0.1 to 5s, 9999/
0, 0.1 to 30s, 9999
*2
0.1s 9999 147
58
Restart cushion time 0 to 60s 0.1s 1s 147

59
Remote function selection 0, 1, 2, 3, 11, 12, 13 1 0 91

 60
Energy saving control selection 0, 4, 9 1 0 158

65
Retry selection 0 to 5 1 0 154

66
Stall prevention operation reduction
starting frequency
0 to 400Hz 0.01Hz 50Hz 74
Retry
67
Number of retries at fault occurrence 0 to 10, 101 to 110 1 0 154
68
Retry waiting time 0 to 10s 0.1s 1s 154
69
Retry count display erase 010154

70
Special regenerative brake duty 0 to 10% 0.1% 0% 108

71
Applied motor 0, 1, 2, 20 1 0 105

72
PWM frequency selection 0 to 15/0 to 6, 25 *2 12164

73
Analog input selection 0 to 7, 10 to 17 1 1 166

74
Input filter time constant 0 to 8 1 1 171

75
Reset selection/disconnected PU
detection/PU stop selection
0 to 3, 14 to 17,
100 to 103, 114 to 117
114181

76
Fault code output selection 0, 1, 2 1 0 156

77
Parameter write selection 0, 1, 2 1 0 184

78
Reverse rotation prevention selection 0, 1, 2 1 0 185

 79
Operation mode selection 0, 1, 2, 3, 4, 6, 7 1 0 190
Simple magnetic
flux vector control
80
Motor capacity
0.4 to 55kW, 9999/
0 to 3600kW, 9999
*2
0.01/0.1kW 9999 72
90
Motor constant (R1)
0 to 50  , 9999/
0 to 400m
 , 9999 *2
0.001/
0.01m
9999 72
Adjustable 5 points V/F
100
V/F1(first frequency) 0 to 400Hz, 9999 0.01Hz 9999 85
101
V/F1(first frequency voltage) 0 to 1000V 0.1V 0V 85
102
V/F2(second frequency) 0 to 400Hz, 9999 0.01Hz 9999 85
103
V/F2(second frequency voltage) 0 to 1000V 0.1V 0V 85
104
V/F3(third frequency) 0 to 400Hz, 9999 0.01Hz 9999 85
105
V/F3(third frequency voltage) 0 to 1000V 0.1V 0V 85
106
V/F4(fourth frequency) 0 to 400Hz, 9999 0.01Hz 9999 85
107
V/F4(fourth frequency voltage) 0 to 1000V 0.1V 0V 85
108
V/F5(fifth frequency) 0 to 400Hz, 9999 0.01Hz 9999 85
109
V/F5(fifth frequency voltage) 0 to 1000V 0.1V 0V 85
PU connector communication
117
PU communication station number 0 to 31 1 0 209
118
PU communication speed 48, 96, 192, 384 1 192 209
119
PU communication stop bit length 0, 1, 10, 11 1 1 209
120
PU communication parity check 0, 1, 2 1 2 209
121
Number of PU communication retries 0 to 10, 9999 1 1 209
122
PU communication check time
interval
0, 0.1 to 999.8s, 9999 0.1s 9999 209
123
PU communication waiting time
setting
0 to 150ms, 9999 1 9999 209
124
PU communication CR/LF selection 0, 1, 2 1 1 209

 125
Terminal 2 frequency setting gain
frequency
0 to 400Hz 0.01Hz 50Hz 172
Function Parameters
Name Setting Range
Minimum
Setting
Increments
Initial
Value
Refer
to
Page
Customer
Setting

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
