Mitsubishi F700 Series User Manual

63
Parameter List
Parameter list
4
PARAMETERS
Maintenance
503
Maintenance timer 0 (1 to 9998) 1 0 300
504
Maintenance timer alarm output set
time
0 to 9998, 9999 1 9999 300

505
Speed setting reference 1 to 120Hz 0.01Hz 50Hz 134
PLC function
506
to
515
Parameter 1 to 10 for user 0 to 65535 1 0 255

522
Output stop frequency 0 to 400Hz, 9999 0.01Hz 9999 115

539
Modbus-RTU communication check
time interval
0 to 999.8s, 9999 0.1s 9999 227
Communication
549
Protocol selection 0, 1, 2 1 0 227
550
NET mode operation command
source selection
0, 1, 9999 1 9999 199
551
PU mode operation command source
selection
1, 2 1 2 199
PID
control
553
PID deviation limit 0 to 100.0%, 9999 0.1% 9999 256
554
PID signal operation selection 0 to 3, 10 to 13 1 0
256,
277
Current average
monitor
555
Current average time 0.1 to 1.0s 0.1s 1s 301
556
Data output mask time 0.0 to 20.0s 0.1s 0s 301
557
Current average value monitor signal
output reference current
0 to 500A/0 to 3600A
*2
0.01/0.1A
*2
Rated
inverter
current
301

561
PTC thermistor protection level 0.5 to 30k, 9999 0.01 9999 100

563
Energization time carrying-over times (0 to 65535) 1 0 136

564
Operating time carrying-over times (0 to 65535) 1 0 136
Multiple
rating
570
Multiple rating setting 0, 1 1 0 79

571
Holding time at a start 0.0 to 10.0s, 9999 0.1s 9999 97

573
4mA input check selection 1, 2, 3, 4, 9999 1 9999 177
PID control
575
Output interruption detection time 0 to 3600s, 9999 0.1s 1s
256,
277
576
Output interruption detection level 0 to 400Hz 0.01Hz 0Hz
256,
277
577
Output interruption cancel level 900 to 1100% 0.1% 1000%
256,
277
Function Parameters
Name Setting Range
Minimum
Setting
Increments
Initial
Value
Refer
to
Page
Customer
Setting

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
