Mitsubishi F700 Series User Manual

64
Parameter list
Pump function
578
Auxiliary motor operation selection 0 to 3 1 0 277
579
Motor connection function selection 0 to 3 1 0 277
580
MC switching interlock time 0 to 100s 0.1s 1s 277
581
Start waiting time 0 to 100s 0.1s 1s 277
582
Auxiliary motor connection-time
deceleration time
0 to 3600/360s, 9999 0.1/0.01s 1s 277
583
Auxiliary motor disconnection-time
acceleration time
0 to 3600/360s, 9999 0.1/0.01s 1s 277
584
Auxiliary motor 1 starting frequency 0 to 400Hz 0.01Hz 50Hz 277
585
Auxiliary motor 2 starting frequency 0 to 400Hz 0.01Hz 50Hz 277
586
Auxiliary motor 3 starting frequency 0 to 400Hz 0.01Hz 50Hz 277
587
Auxiliary motor 1 stopping frequency 0 to 400Hz 0.01Hz 0Hz 277
588
Auxiliary motor 2 stopping frequency 0 to 400Hz 0.01Hz 0Hz 277
589
Auxiliary motor 3 stopping frequency 0 to 400Hz 0.01Hz 0Hz 277
590
Auxiliary motor start detection time 0 to 3600s 0.1s 5s 277
591
Auxiliary motor stop detection time 0 to 3600s 0.1s 5s 277
Traverse function
592
Traverse function selection 0, 1, 2 1 0 292
593
Maximum amplitude amount 0 to 25% 0.1% 10% 292
594
Amplitude compensation amount
during deceleration
0 to 50% 0.1% 10% 292
595
Amplitude compensation amount
during acceleration
0 to 50% 0.1% 10% 292
596
Amplitude acceleration time 0.1 to 3600s 0.1s 5s 292
597
Amplitude deceleration time 0.1 to 3600s 0.1s 5s 292

611
Acceleration time at a restart 0 to 3600s, 9999 0.1s 5/15s *2 147
Speed
smoothing
control
653
Speed smoothing control 0 to 200% 0.1% 0% 165
654
Speed smoothing cutoff frequency 0 to 120Hz 0.01Hz 20Hz 165

665
Regeneration avoidance frequency
gain
0 to 200% 0.1% 100% 294
BACnet MS/TP protocol
726
Auto Baudrate/Max Master 0 to 255 1 255 242
727
Max Info Frames 1 to 255 1 1 242
728
Device instance number (Upper 3
digit)
0 to 419 (0 to 418) 1 0 242
729
Device instance number (Lower 4
digit)
0 to 9999 (0 to 4302) 1 0 242
Function Parameters
Name Setting Range
Minimum
Setting
Increments
Initial
Value
Refer
to
Page
Customer
Setting

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
