109
CHAPTER 3 CPU MODULE FUNCTIONS
3
3.13 Remote Operation
3.13.2 Remote PAUSE
(b) Using a programming tool
Open the "Remote Operation" dialog box.
[Online] [Remote Operation]
(c) By an external device using the MC protocol
Use MC protocol commands.
MELSEC-Q/L MELSEC Communication Protocol Reference Manual
(2) When forcibly keeping output status
To forcibly keep the output status (on or off) in the PAUSE status, provide an interlock with the PAUSE contact
(SM204).
Select "PAUSE" for
execution.
In the PAUSE status, on/off status of
Y70 depends on that of M20.
Turns off in the PAUSE status.
Turns on in the PAUSE status.
To Next Page
