95
CHAPTER 3 CPU MODULE FUNCTIONS
3
3.9 Error Time Output Mode Setting
3.9 Error Time Output Mode Setting
This function determines the output mode (clear or hold) from the CPU module to output modules and intelligent
function modules when a stop error occurs in the CPU module.
For the error time output mode setting by the built-in I/O function, refer to the following.
MELSEC-L CPU Module User's Manual (Built-In I/O Function)
(1) Setting procedure
1. Select a target module under "Type" in the I/O Assignment tab, and click the button.
Project Window [Parameter] [PLC Parameter] [I/O Assignment]
2. Select either of the following items for "I/O Response Time".
"Clear" or "Hold"
To Next Page
