CHAPTER 4 DISPLAY UNIT FUNCTIONS
4
4.3 CPU Settings 4.3.1 Clock setting
4.3 CPU Settings
The internal time of the CPU module can be checked and changed with the display unit.
4.3.1 Clock setting
The internal time of the CPU module can be set.
(1) Screen transition
The following shows screen transition of clock setting.
(2) Setting item
The following table shows items that can be set by clock setting.
Item Setting range Item Setting range
Year 1980 to 2079 Hour 00 to 23
Month 1 to 12 Minute 00 to 59
Day 1 to 31 Second 00 to 59
OK
"Function selection" screen
"CPU settings" screen
"Clock setting" screen
