3.14 Scan Time Measurement
This function displays the processing time of set program section during ladder monitoring. The time required for the
subroutine and interrupt programs can be measured.
(1) Execution
1. Open the "Scan Time Measurement" dialog box.
[Debug] [Scan Time Measurement]
2. Specify the start and end steps and click the button.
When displaying the "Scan Time Measurement" dialog box after specifying the scan time measurement range in the monitor
mode, the start and end steps are set in the specified ranges such as shown below.
To Next Page
