CHAPTER 3 CPU MODULE FUNCTIONS
3
3.16 Interrupt Program List Monitor
3.16 Interrupt Program List Monitor
This function displays the number of executions of an interrupt program.
(1) Execution
Open the "Interrupt Program List Monitor" dialog box.
[Online] [Monitor] [Interrupt Program List...]
Item Description
Interrupt Pointer An interrupt pointer is displayed.
Execute Count
The number of executions of an interrupt program is displayed. This function starts counting after the CPU
module is in the RUN status. When the counting reaches 65536 times, it is reset to 0.
Comment Device comments created to an interrupt pointer is displayed.
