(4) Error clear
Continuation errors can be cleared with the display unit.
Remove the error cause before clearing an error.
For how to remove error causes, refer to the following.
MELSEC-L CPU Module User's Manual (Hardware Design, Maintenance and Inspection)
(a) Operating procedure
Perform the following operation.
"Error clear" screen
1. Select an error to be cleared using the and
buttons and press the button.
↓
"Error clear confirmation" screen
2. Select "YES" using the and buttons and
press the button.
↓
"Error clear completion" screen
3. After the setting is completed, either of the screens
(shown left) appear.
To return the display to the "error clear" screen,
press the button.
OK
OK
OK
