140
With "Execute fall instruction" selected for in the Options dialog box of the programming tool, the fall instruction is executed
when the instruction is in the data written to the CPU module in the RUN status, even if the execution condition (on → off) is
not met. (The same operation as High Performance model QCPU)
[Tool] [Options...]
The corresponding fall instructions are LDF, ANDF, ORF, MEF, PLF, FCALLP, and EFCALLP. The following describes the
operation with and without "Execute fall instruction" selected.
Completion of
online change
END
1 scan
END END00 0
OFF OFF
ON
OFF
OFF
OFF
OFF
ON
ON
ON
ON OFF
X0 status
X0
M0
X0
M0
The fall instruction is executed
even if the execution condition
is off off.
[ PLF M0 ]
X0
A
A
Operation when selecting
"Trailing edge instructions are not executed"
Completion of
online change
END
1 scan
END END00 0
OFF OFF
ON
OFF
OFF
OFF
OFF
ON
ON
ON
ON OFF
X0 status
X0
M0
X0
M0
The fall instruction is not executed
even if the execution condition
is off off.
The fall instruction is not executed
when online change is completed
and the execution condition of
on off is met coincidentally.
[ PLF M0 ]
X0
A
A
Operation when deselecting
"Trailing edge instructions are not executed"
