(6) Memory and data to be stored
: Storable, ×: Not storable
*1 Store parameters (PARAM.QPA) and intelligent function module parameters (IPARAM.QPA) in the same drive.
Otherwise the intelligent function module parameters are invalid.
*2 Only one file can be stored.
*3 This drive cannot be selected as a storage file by the data logging function. To write data to this drive, perform Write PLC
User Data.
*4 The data in which the information of label program configuration is stored.
GX Works2 Version 1 Operating Manual (Common)
File type
Program
Memory
Standard
RAM
Standard
ROM
SD memory card
File name and
extension
(any given name
for ***)
Remarks
Drive 0 Drive 3 Drive 4 Drive 2
Parameter × PARAM.QPA One file per drive
Intelligent function module
parameters
*1
×IPARAM.QPA
One data per
drive
Program × ***.QPG ⎯
Device comment × ***.QCD ⎯
Initial device value × ***.QDI ⎯
File register ×
*2
× × ***.QDR ⎯
Local device ×
*2
× × ***.QDL
One file per
module
Sampling trace ×
*2
× × ***.QTD ⎯
PLC user data × × ***.CSV/BIN ⎯
Source information (simple project)
*4
×SRCINFOM.C32⎯
Source information (structured
project)
*4
× SRCINFOI.C32 ⎯
Drive heading × QN.DAT ⎯
Device data storage file × × × DEVSTORE.QST ⎯
Module error collection file ×
*2
× × IERRLOG.QIE ⎯
Data logging setting file × ×
LOGCOM.QLG,
LOG01 to 10.QLG
⎯
Data logging file × ×
*3
***.CSV ⎯
Menu definition file × × MENUDEF.QDF ⎯
