(2) Memory capacity of files
Memory capacity of files used in the CPU module are different depending on file types. Derive the memory
capacity for each file, referring to the following table.
*1 The value is adjusted by the system so that the total number of bytes including the network parameter settings is
multiple of four.
*2 The value is adjusted by the system so that the number of bytes is multiple of four.
*3 228 is set by default. (It varies according to parameter settings.)
*4 After the decimal point of a value found by "the number of bit device points/16" is rounded up.
File type Memory capacity (Unit: bytes)
Parameter
Default
• L02CPU: 2936(can be increased by parameter setting)
*1
• L26CPU-BT: 2964(can be increased by parameter setting)
*1
Reference
• Boot setting → 84 + (18 × (number of files))
*2
• With CC-Link setting ( MELSEC-L CC-Link System Master/Local Module User's Manual)
• With remote password setting → 92 + (the number of target modules × 10)
*2
, Up to an increment of 172
Intelligent function module
parameter
76 + (28 × the number of modules set) + parameter size for each utility
*2
Program
228
*3
+ 4 × ((number of steps) + (number of steps reserved for online change))
Device comment
74 + 72 + 8 + (total comment data size of each device)
Comment data size per device = 10 + 10250 × a + 40 × b
• a: Quotient of ((number of device points)/256)
• b: remainder of ((number of device points/256)
Initial device value
66 + 44 (number of settings of the initial device value) + 2 × (total number of device points set to the initial device value) + 72
+ 8
File register 2 × (number of device points)
Local device
70 + 6 × (set device type) + 2 × (total number of M and V points)/16 + (number of D and Z points) + 18 × (total number of T,
ST, and C points)/16) × (number of programs where local devices are used)
M, V, D, T, ST, and C indicate the following set devices.
• M: internal relay
• V: edge relay
• D: data register
•T: timer
• ST: retentive timer
• C: counter
• Z: index register
Sampling trace file
362 + (number of word device points + number of bit device points) × 12 + (N1 + N2 + number of word device points × 2 +
(number of bit device points/16) × 2) × the number of traces (total number of executions)
*4
Apply the following values for N1 and N2 according to the items selected under Additional Information on the "Condition
setting" tab of the "Trace Setting" dialog box.
• N1: When "Time" is selected, apply "4".
• N2: When "Program Name" is selected, apply "8".
PLC user data Depends on the value and the number of data
Source information Depends on the specifications of the programming tool
Drive heading 72
Device data storage file
L02CPU: Setting value at formatting (2K to 32K)
L26CPU-BT: Setting value at formatting (2K to 1024K)
Module error collection file 76 + 64 (64 × (value set for the number of storable errors))
Data logging setting file
• For common setting (file name: LOGCOM)••• 96
• Data logging setting (file name: LOG01 to LPG10. Use the same calculating formula for each file)••• 1164 + 8 × (number of
data settings) + 10 × (total number of device points)
