M800S/M80/E80 Series Connection and Setup Manual
31 Device Open Parameter Screen
549
IB-1501269-J
Menu for the device allocation/number of data input
Menu Details
Copy the data of a line where a cursor is placed.
Writes the contents of the data copied (one line) into a line where the cursor is placed.
If the data of the line is changed after the [Line copy] is pressed, the data before change will be written when
pasting it.
Once the line is copied, it can be pasted many times until new area is copied.
Clears all allocation of the parameter in the device open parameter screen.
-Data of the group detail will not be cleared.
When parameter No. is set and [INPUT] key is pressed, the group will be displayed with the parameter No.
set is a top of the group.
A cursor moves to the line of the target group.
The group detail screen corresponding to the group where a cursor is placed will be displayed.
When the group where the cursor is placed is not set, it will be invalid.
Menu for inputting the display format
Menu Details
Change the display format to the decimal format with sign.
When the data type is "WORD (BIT)", it will be changed to "WORD".
Change the display format to the decimal format without sign.
When the data type is "WORD (BIT)", it will be changed to "WORD".
Change the display format to the HEX format.
When the data type is "WORD (BIT)", it will be changed to "WORD".
Change the display format to the BIT format.
The data type is changed to "WORD (BIT)".
Change the display format to the BCD format.
When the data type is "WORD (BIT)", it will be changed to "WORD".
Select whether to display the target group infomation on the each group detail screen to users.
Select whether the input protection of the data protection key 2 is valid/invalid for setting of the target group
information on the each group detail screen to users.
Copy the data of a line where a cursor is placed.
Writes the contents of the data copied (one line) into the line where the cursor is placed.
If the data of the line is changed after [Line copy] is pressed, the data before change will be written when
pasting it.
Once the line is copied, it can be pasted many times until new area is copied.
Clears all allocation of the parameter in the device open parameter screen.
(Note) Data of the group detail will not be cleared.
When parameter No. is set and [INPUT] key is pressed, the group will be displayed with the parameter No.
set is a top of the group.
A cursor moves to the line of the target group.
The group detail screen corresponding to the group where a cursor is placed will be displayed.
When the group information, where a cursor is placed, is not set, it will be invalid.
Group
details
W/ DEC
sign
W/O DEC
sign
HEX
BIT
BCD
Enable
display
Group
search
Group
details
