MLC LC100 - Page 92

92
LC100 Instruction manual
4/6 Parameters
4/12 Door
Type D
D-24
B-side automatic door open in stations 9 to 16
---
Defining stations in which elevator waiting with door B open. For stations 9 to
16. Parameter has function with automatic landing door B D-14=1 or 3.
Symbol „ “below the number means that elevator waits in that station with door
open.
Example shows that elevator in standby in stations 14, 15 and 16 waiting with
door open. In other stations keeps door closed.
D-25, D-26, D-27
Door B open
---
D-25 - same as D-24 but for stations 17 to 24
D-26 - same as D-24 but for stations 15 to 32
D-27 - same as D-24 but for stations 33 to 40
D-28
Preopening
0-1
Door preopening:
0 – Door preopening off.
1 – Door preopening on.
D-29
Preopening delay
0-2,5s
Door open delay time in preopening mode.
D-30
Passenger passing time
0-25s
Door open time when elevator comes to the station.
D-31
Passenger passing time after photocell
0-25s
Passenger passing time after photocell input is activated or landing door
opening if not automatic.
Interrupting FI-263 or FI-273 open door time is set by parameter.
