Moog T200 User Manual

SECTION 4: MOTOR GUIDE T200 User's Manual
PAGE 4-9
4.3.2.1 Example using SSM command
The motor nameplate shows a Motor Model of G404-123A (i.e. a non-standard motor model) and an electrical Type of
G4L20. By checking for G4L20 in the left hand column of Table 4.2, the user finds that the equivalent standard motor
is a G424-600. He uses the SSM command. He enters the string 'G424-600' and the T200 is configured automatically
with the correct electrical parameter set.
Electrical
Type
'Standard' Motor
String to be
entered via
Command Line
Interface
Electrical
Type
'Standard' Motor
String to be
entered via
Command Line
Interface
G2L05 G422-200 G4L20 G424-600
G2L10 G402-400 G4L40 G424-800
G2L20 G422-600 G5L10 G425-200
G2L40 G422-800 G5L20 G425-400
G3L05 G423-200 G5L30 G425-600
G3L15 G423-400 G5L50 G425-800
G3L25 G423-600 G6L15 G426-200
G3L40 G423-800 G6L30 G426-400
G4L05 G424-200 G6L45 G426-600
G4L10 G424-400 G6L60 G426-800
Table 4.3 Electrical Type and Standard Model Equivalency Table
If the motor electrical type is not listed in the Table above, then the user should consult Moog Applications Engineering
for support on motor entry.
