T200 User's Manual SECTION 10: TROUBLE-SHOOTING GUIDE
PAGE 10-4
10.1 Introduction
The following tables list typical system, controller, and motor troubleshooting conditions. A list of possible cause(s) is
given for each condition. For some conditions, there are multiple possible causes which are generally listed in order of
increasing complexity or decreasing likelihood for the stated conditions. A list of check/correct action recommendations
are listed below each possible cause(s).
The T200 provides extensive diagnosis of fault conditions and warnings, as well as high power status information. This
diagnostic information is intended to aid in the troubleshooting of applications and controller problems. The following
sections explain why high power status LED are illuminated, and what problem sources can cause faults and warnings to
be displayed on the 7-segment display. Additional diagnosis information is provided for other sources of faults.
WARNING: Do not attempt to repair or make internal adjustments to the controller or
power supply. Lethal voltages are present and changes to factory calibration can result
in serious equipment and/or personnel risk and void the equipment warranty. All faulty
items of this equipment must be returned to Moog Service Centres for maintenance and
repair.
