SECTION 6: T200 FUNCTIONAL OVERVIEW T200 User's Manual
PAGE 6-35
The diagram above outlines the operation of the T200 in torque mode. Note that Automatic/Manual mode is controlled
by the Auto_Man digital input. However the switch-over between Automatic and Manual modes can be disabled by
disabling the Manual Mode, leaving the T200 permanently in Automatic Mode (full power mode).
