SECTION 6: T200 FUNCTIONAL OVERVIEW T200 User's Manual
PAGE 6-65
:- The T200 Encoder Simulation Output is galvanically isolated.
There is a maximum rate of pulses which may be transferred without loss of position
information, through the isolation circuitry. The maximum pulse rate for the Channel A,
Channel B and Zero-Marker is 200kHz. The user is informed by the WinDrive interface what is
the maximum motor rotational speed for that number of Lines-Per-Revolution.
NOTE on Line-counts and Control Modes
ESM3 Linecounts (128, 256, 512 or 1024) are recommended for use when the T200 is
operated in torque mode.
Other even line-counts (any even number between 100 and 8000, excepting those listed
above as ESM3 linecounts) can be used when the T200 is operated in velocity mode
