A - 4 MC40 Integrator Guide
Decode Zone
Figure A-1 shows the decode zone for the SE4500-DL imager. Typical values appear. Table A-3 lists the typical
distances for selected bar code densities. The minimum element width (or “symbol density”) is the width in mils
of the narrowest element (bar and space) in the symbol.
Table A-2
Data Capture Options
Item Description
1D Bar Codes Chinese 2 of 5 Codabar Code 11
Code 128 Code 39 Code 93
Coupon Code Discrete 2 of 5 EAN-8
EAN-13 GS1 DataBar GS1 DataBar 14
GS1 DataBar Expanded GS1 DataBar Expanded Stacked
GS1 DataBar Limited Interleaved 2 of 5 ISBT 128
Korean 2 of 5 Matrix 2 of 5 MSI
TLC39 Trioptic 39 UCC/EAN 128
UPCA UPCE UPCE1
UPC/EAN Supplementals Webcode
2D Bar Codes Australian Postal Aztec Canadian Postal
Composite AB Composite C Data Matrix
Dutch Postal Japanese Postal Linked Aztec
Maxi Code Micro PDF-417 microQR
PDF-417 QR Code US Planet
UK Postal US Postnet USPS 4-state (US4CB)
