Specifications A - 3
Rear-facing Camera For bar code scanning and image capture: 8 MP auto-focus camera with
aiming; captures 1D and 2D bar codes, photographs, video, signatures and
documents.
Magnetic Stripe Reader Reads data on magnetic stripe cards.
Sensors
Motion Sensor 3-axis accelerometer that enables motion sensing applications for dynamic
screen orientation and power management.
Ambient Light/Proximity Sensor Automatically adjusts display brightness and turns off the display during
PTT calls.
Imager (SE4500-DL) Specifications
Field of View Horizontal - 39.2°
Vertical - 25.4°
Optical Resolution WVGA 752 H x 480 V pixels (gray scale)
Roll 360°
Pitch Angle +/- 60° from normal
Skew Tolerance +/- 60° from normal
Ambient Light Indoor: 450 ft. candles (4845 lux)
Outdoor: 9000 ft. candles (96,900 lux)
Sunlight: 8000 ft. candles
Fluorescent: 450 ft. candles
Focal Distance From center of exit window: 18.5 cm (7.3 in.)
Aiming Element (VLD) 655 nm +/- 10 nm
Illumination Element (LED) 625 nm +/- 5 nm
Table A-1
MC40 Technical Specifications (Continued)
Item Description
