Accessories 2 - 7
Figure 2-6
Setup with 2-way DC Cable
Four Charger Setup
To setup four Four Slot Battery Charger:
1. Plug the 4-way DC Cable plugs into the power port on the back of the each charger.
2. Plug the 4-way DC Cable connector into the power output of the power supply.
3. Plug the AC line cord into the power supply.
4. Plug the AC line cord into an AC outlet.
AC Line Cord
Power Supply
2-way DC Cable
To Next Page
