Accessories 2 - 13
Figure 2-14 Five Slot Universal Charge Only Cradle Power Connections
The Charging Cup contains an insert. Remove the insert when charging an MC40 with a rubber boot.
Figure 2-15 Remove Insert
Charging
Insert the MC40 into a slot to begin charging.
The Right LED indicates the status of the battery charging in the MC40. See Table 1-1 on page 1-3 for
charging status indications. The 2680 mAh battery charges in approximately four hours.
