4 - 26 MC40 Integrator Guide
Delete an Action
To delete an action from the Actions list, touch and hold the action name and select Delete action from the
context menu.
ADF Example
The following illustrates an example of creating advanced data formatting:
When a user scans a bar code with the following criteria:
•
Code 39 bar code
•
length of 12 characters
Data Modification Crunch spaces Remove spaces between words to one and remove all
spaces at the beginning and end of the data.
Stop space crunch Stops space crunching. This disables the last Crunch
spaces action.
Remove all spaces Remove all spaces in the data.
Stop space removal Stop removing spaces. This disables the last Remove all
spaces action.
Remove leading zeros Remove all zeros at the beginning of data.
Stop zero removal Stop removing zeros at the beginning of data. This disables
the previous Remove leading zeros action.
Pad with zeros Left pad data with zeros to meet the specified length. Enter
the number zeros to pad.
Stop pad zeros Stop padding with zeros. This disables the previous Pad with
zeros action.
Replace string Replaces a specified string with a new string. Enter the string
to replace and the string to replace it with.
Stop all replace string Stop all Replace string actions.
Data Sending Send next Sends the specified number of characters from the current
cursor position. Enter the number of characters to send.
Send remaining Sends all data that remains from the current cursor position.
Send up to Sends all data up to a specified string. Enter the string.
Send pause Pauses the specified number of milliseconds before
continuing the next action. Enter the amount of time in
milliseconds.
Send string Sends a specified string. Enter the string to send.
Send char Sends a specified ASCII/ Unicode character. Enter a
character value. The maximum Unicode character value can
be entered is U-10FFFF (= 1114111 in decimal).
Table 4-1
ADF Supported Actions (Continued)
Type Actions Description
