MTC-134

MODE DOOR MOTOR

Revision: January 2005 2004 Quest

3. Disconnect the mode door motor electrical connector.

4. Remove the three screws and remove the mode door motor.

INSTALLATION

Installation is in the reverse order of removal.

LJIA0083E
