SERVICE DATA AND SPECIFICATIONS (SDS)
MTC-163
C
D
E
F
G
H
I
K
L
M
A
B
MTC
Revision: January 2005 2004 Quest
SERVICE DATA AND SPECIFICATIONS (SDS) PFP:00030
Service Data and Specifications (SDS) EJS001TX
COMPRESSOR
LUBRICANT
REFRIGERANT
ENGINE IDLING SPEED
Refer to EC-35, "Idle Speed and Ignition Timing Check" .
BELT TENSION
Refer to MA-13, "Tension Adjustment" .
Make ZEXEL VALEO CLIMATE CONTROL
Model DKS-17D
Type Swash plate
Displacement
cm3 (cu in) / rev
175.5 (10.7) / rev
Cylinder bore × stroke
mm (in)
30.5 (1.201) x 24.0 (0.94)
Direction of rotation Clockwise (viewed from drive end)
Drive belt Poly V
Make ZEXEL VALEO CLIMATE CONTROL
Model DKS-17D
Name NISSAN A/C System lubricant Type DH-PS
Part number KLH00-PAGS0
Capacity
m (US fl oz, lmp fl oz)
Total in system 220 (7.44, 7.7)
Compressor (service part) charging amount Refer to MTC-22, "
CHECKING AND ADJUSTING" .
Type HFC-134a (R-134a)
Capacity
g (lb)
900 ± 50 (1.98 ± 0.11)
