Users Guide ValueJet 1614
115 AP-75790  Rev 1.4 -22/02/2011,
Step 5 : Pull the media to your side, and cut the torn part with cutting tools such as a razor blade.
î
í
ï
N° Name
1 Razor blade
2 Roll media
Step 6 : Turn the flanges of the roll media holders and wind roll media.
ïï î
N° Name
1 Flanges
2 Roll media
Step 7 : If paper dust or pieces of paper remain inside the printer, remove them.
