6.2 WHEN MEDIA IS JAMMED
Be sure to read and understand the safety warnings before handling the printer.
Step 1 : Switch OFF the power of the printer.
Refer to Switching the power OFF
Step 2 : Open the front cover.
Step 3 : Move the print head section from the top of the media to the right.
î
ï
N° Name
1 Print head section
2 Roll media
Step 4 : Raise the media loading lever.
ï
N° Name
1 Media loading lever
