4.5 ADJUST PRINT
Notes
This printer has been adjusted for optimum print quality before shipment at the Mutoh factory.
Align the print head when the print quality decreases after the installation environment or the media has
been changed.
Be sure to read and understand the safety warnings before handling the printer.
Align the print head as described in the following procedure:
Step 1 : Switch ON the printer.
Step 2 : Load more than A3 size print media.
Step 3 : Confirm that the printer functions normally.
Step 4 : Press the [Menu] key on the operation panel.
Result:
The operation panel displays "Menu 1: Setup>".
Shifts to the Setup menu display.
Step 5 : Press the [>] key on the operation panel.
Set1: MediaType is displayed on the operation panel
Step 6 : Press the [+] or [] key on the operation panel to select the media type to use.
Step 7 : Press the [Enter] key on the operation panel.
**>1: PrintMode is displayed on the operation panel.
Step 8 : Press the [Enter] key on the operation panel.
Mode: quality 1 will be displayed on the operation panel.
The display shifts to the printing mode menu.
Select the printing mode you want to use.
Step 9 : Press the [+] or [] key on the operation panel to select "Adj.4: Bi-D Quality".
Step 10 : Press the [CANCEL] key on the operation panel several times.
The operation panel shifts back to normal.
Displays the adjustprint menu on the operation panel.
Step 11 : Press the [menu] key on the operation panel.
Menu1:Setup> is displayed on the operation panel
The operation menu shifts to the setup menu display.
Step 12 : Press the [+] key or [-] key to select Menu3: Adjust print
Step 13 : Press the [>] key on the operation panel.
Adj 1 Confirm is displayed on the operation panel.
The display enters the adjustprint menu.
Step 14 : Press the [Enter] key on the operation panel.
