Users Guide ValueJet 1614
72 AP-75790 Rev 1.4 -22/02/2011,
4.7.1 MediaType menu
Setup item Setting Value Description
Media
Type 1 Set up the media type for printing.
It is possible to set 30 different user settings as
"Type 1-30" for printing.
[Enter] key: Shift to the next hierarchy.
refer to: User media menu
Type 2
...
Type 29
Type 30
[Cancel] key: Save the setting value and shift to
the previous hierarchy.
refer to Setup menu
4.7.1.1 User media menu
Notes
If non-compatible media is used, the following problems may occur:
± Media detection error
± Slant, snag and wrinkle of media
± Media jams
± Optimum printing quality cannot be obtained due to blots, blurs and dirt of ink.
± End detection of roll media cannot be performed, etc.
The problems caused by the use of non-compatible will not be covered by the warranty and repair
expenses will be paid by the customer.
For details, contact your MUTOH local dealer.
Setup item Setting Value Description
Type 1 to 30
Print mode
Set up the print mode according to the used print
data or print speed.
[Enter] key: Shift to the next hierarchy.
refer to Print mode menu
PF Adjust
Various settings on the Media feed compensation
can be set.
[>] key: Shift to the next hierarchy.
refer to Dist. Adj menu
Pre Heater
Set up the Pre Heater temperature.
[Enter] key: Shift to the next hierarchy.
refer to Pre heater menu
Fixer (platen)
Set up the Platen Heater temperature.
[Enter] key: Shift to the next hierarchy.
refer to Platen heater menu
Dryer
Set up the After Heater temperature.
[Enter] key: Shift to the next hierarchy.
refer to After heater menu
StandbyHeating
Set up whether the heater is preheated while in
standby mode.
[Enter] key: Shift to the next hierarchy.
refer to StandbyHeating menu
Vacuum Fan
Set up the vacuum fan operation
[Enter] key: Shift to the next hierarchy.
refer to Vacuum fan menu
[Cancel] key: Shift to the previous hierarchy.
refer to Media type menu
