Users Guide ValueJet 1614
47 AP-75790  Rev 1.4 -22/02/2011,
4.3.2 Setting roll media
Notes
There are two optional winding systems available for the ValueJet 1614
± Unwinder/Winder 100
± Motorized winding system with tensioning (T winder)
Please refer to the User Guide of the chosen system to know how to correctly load media
Refer to the pricing sheet for more details of these systems.
If you do not use one of the above winding systems. You have to use the scroller which is supplied with
the printer.
Be sure to read and understand the safety warnings before handling the printer.
Step 1 : Switch ON the printer.
The printer starts the initializing operation.
Media End is displayed on the operation panel.
Step 2 : Raise the media loading lever.
ï
N° Name
1 Media loading lever.
Lever Up is displayed on the operation panel.
