Users Guide ValueJet 1614
48 AP-75790  Rev 1.4 -22/02/2011,
Step 3 : Open the front cover.
ï
N° Name
1 Front Cover
Step 4 : Set the roll media to the media feed slot.
Notes
If the end of the roll media is not wound tightly, wind it tightly again, and then load it.
ï
î
N° Name
1 Roll media
2 Media feed slot
Step 5 : Pull the roll media out about 1m from the front media feed slot which is located inside of the front
cover.
ï
î
N° Name
1 Roll media
2 Media feed slot
