Users Guide ValueJet 1614
49 AP-75790  Rev 1.4 -22/02/2011,
Step 6 : Rewind the roll media a little by rolling the flange on the roll media holder while holding the edge
of the media, eliminate any slack or slant.
Notes
If you set the roll media free while rewinding, the roll media will fall out from the media feed slot on the
rear of the product.
Confirm that the right edge of the roll media does not go beyond the loading mark. If it does, it may
affect print quality.
ï
ï
î
N° Name
1 Roll media
2 Media loading mark
Notes
When setting the roll media, set both sides of the media at least 5mm away from the edge of the
pressure roller. Slippage or creases may occur during printing.
볳 볳 볳볳
î
ï
î
ï
î
ï
N° Name
1 Roll media
2 pressure rollers
